Sanwa SV-Plus Zero ESC for EU (SA107A41268A)
SA107A41268A – SV-Plus Zero ESC for EU
SAMWA SV-Plus Zero ESC for EU
Built-In Receiver (RX-472)
2.4GHz frequency hopping spread spectrum (FHSS4)
– Back Cancel
– Boost Zero Indication
– SSR/SHR/NOR Automatic Recognition & Indication
– 8 Programming Mode
– Full Brake Rate
– Neutral Brake Rate
– Drive Feel
– Neutral Brake Feel
– Brake Feel
– Boost Timing (Advanced Timing)
– Turbo
– Power Mode
– SSL function
– Meet the requirements of the regulation “boost off”
– Checked by connection to TH Channel & LED Blue Light Flashing
Nominal Input Voltage – 6.0~7.4V
Rated Current – 740A
Resistance loss – 0.00038ohm
Dimensions – 36.6×37.8×26.9mm
– Maximum Motor Power Value
Reduction of loss resistance and control efficiency upgrade the control of temperature increase and basic functions so much.
– Multi-Protection System
Protection against low voltage, sensor cable trouble, motor lock, overheat of body overheat of motor (*1) *1; Compatible only with built-in temperature sensor motor
– Direct Copper Designed Terminal
Direct connection of power wire save the loss at most.
– Compatibility with Multi-Battery
Cut-Off Voltage setting enables compatibility with multi-battery.
