Spektrum 1.9-Gram Linear Long Throw BB Servo (SPMAS2000LBB)
The AS2000LBB is a ball-bearing version of the AS2000L servo. It’s a high performance micro-weight servo used in ultra-micro heli and plane applications and is compatible with the AR6400 series of Spektrum receivers.
Ultra-micro aircraft builders will want the 2000LBB for the better control surface centering and robust action aggressive 3D flight demands.
1.9gm Linear Long Throw Ball Bearing Servo Features:
- Compact footprint
- JST-SHR connector type
- Two ball bearings
- 9.1mm servo throw
1.9gm Linear Long Throw Ball Bearing Servo Specifications:
- Application: Ultra micro aircraft
- Bushing Or Bearing: Bearing
- Connector Type: JST-SHR
- Gear Type: Plastic
- Height: 0.33 in (8.2mm)
- Length: 0.87 in (22.0mm)
- Servo Type: Analog
- Servo Voltage: 3.2 – 4.2V
- Size Category: Minis and Micros
- Speed: 0.14 sec
- Speed (at 4.8V): .10 – .14 sec
- Torque: 2.8 oz (79.4 g) forc
- Torque (at 4.8V): Less than 20 oz-in
- Weight: 0.07 oz (1.9g)
- Width: 0.66 in (16.9mm)
